Feature
Low cost
Bright LED 0.8'(red)
Input 0-5A(Current Transformer)can adjust fullscale 200-1999
AC20V,200V,600V measurement Power supply 145V-245V |
|
|
|
| Specifications |
| Input mode |
Single ended |
| A/D conerter |
Dual slope |
| Sampling time |
ABt.2.5sec |
| Over Range |
"-1"or"1" |
| Display |
Red LED(14.2mmH) |
| Polarity display |
Display"-"only |
| Power supply |
145V-245V 50Hz/60Hz |
| Power consumption |
≤1.5VA |
| Dielectic strength |
Ac1500V1min |
| Insulation Res. |
DC500V≥100MW |
| Operation Temp. |
1-50 |
| 抗串模干擾 |
≥NMR40db(50Hz/60Hz) |
|
 |
 |
 |
|
|
